Nightstand plans

This step by step diy woodworking project is about nightstand plans. If you want to learn more about building a basic nightstand, we recommend you to pay attention to the instructions described in the article. There are so many designs and plans to choose from when building a nightstand, so make sure you take a look over the related woodworking projects that are featured on our site.

Before starting the actual construction project, we recommend you to plan everything, as to save money and to keep the costs under control. Adjust the size and the design of the nightstand to suit your needs. In addition, we recommend you to invest in high-quality materials, such as pine, redwood or cedar, as they have a nice finish and are highly durable, especially in a humid environment.

If you don’t have a rich expertise in woodworking field, you should ask a friend to give you a hand with the project. There are many things that you could go wrong, so make sure you plan everything and invest in quality materials. Select the lumber with attention, making sure the components are perfectly straight and in a very good condition. Use a carpentry square to check if the corners are right-angled. See all my Premium Plans in the Shop.



Made from this plan

Add-Image



Nightstand plans

Building a nightstand

Building a nightstand



Materials

  • A – 4 pieces of 2×2 lumber – 3″ long, 2 pieces of 1×2 lumber- 13″ long, 2 pieces – 9″ long BASE
  • B – 2 pieces of 3/4″ plywood – 16″x19 1/4″ long, 2 pieces – 16″x20″ long FRAME
  • C – 2 pieces of 3/4″ plywood – 18 1/2″x19 1/4″ long BACK
  • D – 1 piece of 3/4″ plywood – 15 1/4″x18 1/2″long, 2 pieces of 1×2 lumber – 18 1/2″ long SHELVES
  • E – 2 pieces of 1×6 lumber – 13″ long, 2 pieces – 17″, 1 pieces of 3/4″ plywood – 13″x15 1/2″ long, 1 piece – 6 3/4″x18 1/4″ long DRAWER

  • 1 piece of 3/4″ plywood – 4’x8′
  • 1 piece of 2×2 lumber – 1 ft
  • 1 piece of 1×2 lumber -8 ft
  • 1 piece of 1×6 lumber – 8 ft
  • 2 1/2″ screws
  • 1 1/4″ screws
  • glue, stain
  • wood filler
  • slides
  • drawer pull

Tools

Tips

  • Apply several coats of wood stain to the wooden components
  • Fill the holes with wood filler and smooth the surface

Time

  • One Day

Related





Building a nightstand

Building the frame of the nightstand

Building the frame of the nightstand



The first stand of the project is to build the frame of the nightstand. In order to get a professional result, we recommend you to cut the components at the right size and to lock them together properly. Drill pocket holes at both ends of the side components and secure them to the bottom component with 1 1/4″ screws. Add waterproof glue to the joints, in order to get an accurate result.



Building the base of the nightstand

Building the base of the nightstand



Continue the project by attaching the base to the nightstand. Drill pocket holes at both ends of the horizontal components and secure them to the legs. Make sure the corners are right angled, before inserting the galvanized screws. Drill pilot holes through the supports and secure them to the bottom of the nightstand. Add waterproof glue to the joints in order to enhance the bond of the structure.



Fitting the back

Fitting the back



Cut the bottom of the nightstand out of 3/4″ plywood and fit it to the frame of the structure. Drill pocket holes along the edges of the piece of plywood and secure it to the structure with 1 1/4″ screws. Add glue to the joints in order to get a professional result.



Fitting the shelves and the supports

Fitting the shelves and the supports



Build the supports out of 1×2 lumber and drill pocket holes at both ends. Fit them between the sides of the nightstand, align them with attention and secure them into place ny using 1 1/4″ screws. In addition attach the shelf into place and secure it to the frame of the stand with galvanized screws.



Attaching the top

Attaching the top



Drill pocket holes through the top of the component and insert 1 1/4″ screws into the tabletop. Make sure you leave no gaps between the components and add waterproof glue to enhance the rigidity of the joints. Make sure the corners are right-angled after fitting each components.



Building the drawer

Building the drawer



Build the frame of the drawer out of 1×6 slats and the bottom out of 3/4″ plywood. Drill pocket holes at both ends of the side components and inset 1 1/4″ screws into the perpendicular components. Drill pocket holes along the edges of the bottom component and secure it to the frame with 1 1/4″ screws. Add glue to enhance the rigidity of the frame.



Fitting the drawer into place

Fitting the drawer into place



Fit the drawer inside the frame of the nightstand and secure it to the sides of the frame using metal slides. Check if the drawer opens and closes properly, before attaching the face and the handle.



Attaching the drawer face

Attaching the drawer face



Fit the face to the drawer, making sure you leave about 1/8″ around the edges. Drill pilot holes through the drawer and insert 1 1/4″ screws into the face of the drawer. Leave no gaps between the components, in order to get a professional result.



Nightstand plans

Nightstand plans



Last but not least, we recommend you to take care of the finishing touches. Fill the holes with wood filler and let it to dry out for several hours. Afterwards, smooth the wooden surface with fine-grit sandpaper and vacuum the residues.

Smart tip: Apply several coats of stain or paint to the wooden components, if you want to protect them from decay and to enhance the look of the nightstand. If you want to get this plan as a PDF file, please take a look over the GET PDF PLANS button bellow. Thank you for the support!





Thank you for reading our project about nightstand plans and we recommend you to check out the rest of the projects. Don’t forget to share our projects with your friends and LIKE us, by using the social media widgets, if you want to be the first that gets our latest articles.
